| 1. Unique door-free structure and big
2. LCD screen, making it easier and more convenient to operate, in the meanwhileavoiding problems of pump stuck and fluid leakage.
3. Unique function of bedside infusion supervision, making patients and their relatives more assured while reducing nurses' workload. If used with 2000II and Data Collector a bed No. can be set in the machine and then its infusion progress and alarm information can be displayed on 2000II located at Nurse's Station and SK Data Collector terminal. The nurse, upon seeing and hearing the signal, can go and handle the unit accordingly.
4. All brands of standard IV sets are compatible. With only a simple calibration, it can guarantee an accurate, smooth and safe infusion.
5. When detecting air in line or occlusion, an audio and visual alarm signal shall be given instantly while at the same time the machine stops operation automatically, thus reducing the danger of air embolism to patients.
6. The infrared sensor shall give alarm signal when detecting excessive air pressure.
7. Application of double CPU, making the infusion process safer and more reliable.
8. Alarm signals are given in case of malfunction or operation error and the machine stops operation automatically.
Applicable IV sets |
All brands of standard IV sets |
|
Weight |
< 3.0kg |
Mechanism |
Peristaltic |
|
Dimension |
265 × 230 × 175mm (length×width×height) |
Accuracy |
±3% |
|
Power supply |
AC100-240V,50/60 Hz, |
Pressure |
39.2kPa~137.2kPa |
|
Fuse |
T2AL250V~ |
Model |
600I |
Infusion rate |
600I |
1-600ml/h
(increment 1 ml/h)
|
Maximum power consumption
|
25W,can run for 4 hours continuously after being recharged. |
600IB |
1-2000ml/h
(increment 1 ml/h)
|
Battery |
Rechargeable lithium polymer battery,7.4V,1600mAh |
Accumulated infusion volume |
1ml-9999ml |
Battery recharge |
When the pump is connected to the AC power supply, turn on the power and the battery will automatically recharge (about 8-14 hours to recharge fully). |
Volume limit |
1ml-999ml(increment 1ml/h) |
Electrical safety
|
Comply with the stipulation of IEC60601-1: 1996 |
Displayed information |
Rate, volume limit, accumulated volume, power indicator light, bed No., AIR, OCCL., OVER. EMPTY. |
Electromagnetic compatibility |
Comply with the stipulation of IEC6 0601-1-2 : 2006 |
Shell material |
ABS plastic |
Alarm functions |
Over, OCCL., AIR, Empty, low battery, control abnormal, no AC power supply, installation error, serious low battery. |
Classification |
Class II , Type BF |
KVO flow rate |
1ml/h,(keep vein open rate ) |
Operating conditions |
Environment temperature 5°C ~ 40°C , air pressure 80kPa ~106kPa, relative humidity <8 0% |
Bolus rate |
600ml/h |
Storage conditions |
Environment temperature -40°C ~ 55°C , air pressure 50kPa ~106kPa, relative humidity <95 % |
Applied standards |
IEC60601-1: 2005
IEC6 0601-2-24 : 1998
IEC6 0601-1-2 : 2006
ISO780-1997
ISO15223: 2000
ISO7886-1: 1993
ISO / IEC: Guide No. 37<Consumer Goods Usage Instructions>
|
|
|
