| Microscope |
Microscope Type |
Converging stereoscope microscope |
| Magnification selection |
two steps magnifications |
| Eyepiece |
10X |
| Magnification Ratio(Field of view) |
10X(18mm),16X(14.5mm) |
| Pupillary Adjustment |
50mm ~ 82mm |
| Diopter Adjustment |
+- 5D |
| Base |
Side Shift |
110mm |
| Depth shift |
90mm |
| Height shift |
30mm |
| Chin rest |
Height Shift |
80mm |
| Fixation Target |
Red LED |
| Illumination system |
Slit Width |
0 ~ 9 mm Continuous ( at 9mm , slit becomes a circle ) |
| Slit Height |
0 ~ 8mm Continuous |
| Slit Angle |
0° ~ 180° adjustable |
| Slit Inclination |
0° ~ 23 ° |
| Diameter of Light Spot |
Ø9mm, Ø8mm , Ø5mm, Ø3mm, Ø2mm, Ø1mm, Ø0.2mm |
| Filter |
Heat Absorption , Grey ,Red-Free , Cobalt Blue |
| Illumination Bulb |
12v 50w halogen lamp |
| Power |
Input Voltage |
110V / 220V AC |
| Frequency |
50 / 60 HZ |
| Power Consumption |
68 VA |
| Weight and Size |
Gross Weight |
18kg |
| Dimension |
690mm(L) × 440mm(W) × 420mm (H) |
|
|
|
