Features
1. Can be used in ward and emergency treatment room.
2. X-ray generator is combined
3. Single focus, bridge rectification.
4. It is precise, safe, reliable and flexible
5. A wireless remote control device (control range>8 m) is used
Main specifications
X-ray generator |
Stationary anode, single focus, and bridge silicon rectification, The X-ray generator is an oil-immersed self-cooled unit. |
Max rated capability |
Current |
15mA |
30mA |
60mA |
100mA |
Voltage |
90kvp |
90kvp |
90kvp |
80kvp |
Time |
6.3s |
6.3s |
4.0s |
3.2s |
Power supply |
Voltage |
180~240V |
Frequency |
50Hz |
Power |
not lower than 7kVA |
Resistance |
not larger than 1degree |
Voltage adjustment range of x-ray tube |
50~90kVp |
Range of the timer |
0.08~6.3 s |
Distance between the focus to the ground |
700~1780 mm |
X-ray tube focus transverse rotation |
60 degree |
Specification of X-ray tube |
XD4 2.9/100
Stationary anode, single focus |
Transport dimension, Weight |
Size: 90×130×205cm
NET Weight: 159kg, GROSS Weight: 256kg |
|
 |
