Working Frequency: 2.0-10.0 MHz
Probe Connector: 2
Scan Mode: Electronic linear and convex
Display Modes: B, B/B, 4B, B/M, M
Gray Scales: 256
Monitor: 10" SVGA
Focus Mode: 8-segment focusing
Gain/Dynamic Adjustment: Electronic Adjustment
Max. Measurement Depth: 240mm
Frequency Conversion: 4 Methods
Gama Correction: 8 curves
Frame Correlation: 4
Image Amplification: 16 times, partial amplify and high-definition conversion
Image Storage: 32 images (4 images can be viewed simultaneously)
Four Image Amplification: *1.0， *1.2，*1.5，*2.0 and part amplification
Back light keypad
USB
Standard: 3.5M Convex Probe
Optional: Trolley, Vedio Printer, 6.5M Transvaginal Probe, 7.5M Leaner Probe
 |
Download Literature: |
PW-6018
Right click and save as... to download the literature |
|
|
|
