Features:
Batch analyzer
Insert STAT sample at any time during testing
Online display analyse state, giveing immediate analysis information
Intelligent multi task software
User-friendly software in English, French, Spaninsh, Russian versions and otehr language software available on request
Perfect quality control funcion with Levy-Jennings chart and Westguard analysis available
Automatic Flow cell washing and probe washing between each test to effectively minimize carry-over
Auto-check and auto-alarm to ensure the analyzer in good condition
New long life pump, no tubing wearing problem any more
Less service and maintenance needed
Specifications
Throughput |
140 tests per hour |
Test Methods |
End point, Kinetic, Fixed time, Bi-chromatic, Multi-standard, Two-step end-point and etc. |
Calibration |
Linear or Nonlinear with 1-6 standards calibration |
System Calibration |
Deduction of washer blank/ reagent blank |
Sample Position |
64 positions including sample, calibrator/standard, control and stat |
Sample Volume |
1-100ul, 1ul/step |
Sample Probe |
With liquid detection and crash-protect function |
Reaction Tray |
96 reaction cuvettes |
Flow Cell |
32ul, automatically washing |
Optioal System |
6V/10W halogen lamp
7 high quality narrow band filters and 2 more filter positions
Photometric measuring range: 0-3.0 OD |
Diluter |
1000ul, 1ul/step |
Temperature |
37+0.1
°C
|
Strorage Capacity |
Memory of more than 200 programs and on million test results |
External Deivece (on request) |
Pentium IV PC, printer, monitor |
Power supply |
AC 110/ 220V, 50/60Hz |
Interface |
USD 2.0 |
Dimension |
60cm x 50cm x 41cm |
|
|
